tortuise

Gaussian splats viewer that works in your terminal. Yes, it’s made of symbols!

A CPU-first 3D Gaussian Splatting viewer inspired by ratatui, built on crossterm. Fully parallelized rendering pipeline via rayon, perceptual color mapping, six render modes — all running on pure CPU. Real scenes with 1.1M splats hold 10–25 FPS. No GPU required. Works on potato.

Why this exists

Gaussian Splats are cool. Beautiful tech. Especially now with the rise of image-to-splat pipelines like SHARP. Btw, it will be soon available here.

Inspiration by ratatui merged with binge watching of Common Side Effects which resulted in building this “The Tortuise” TUI 3GS viewer.

Features

Feature	Details
6 render modes	Halfblock (default), point cloud, matrix, block density, braille, ASCII. Cycle with M
Full 3D navigation	WASD movement, R/F vertical, arrow keys for yaw/pitch. Smooth held-key input
Two camera modes	Free (fly anywhere) and Orbit (auto-rotate around origin). Switch with Space
.ply and .splat files	Standard 3DGS formats. Binary little-endian PLY with SH coefficients, 32-byte .splat records
Built-in scenes	Bundled bonsai.splat (1.1M splats) and luigi.ply (14K). --demo runs a built-in demo scene
Terminal detection	Truecolor for modern terminals, perceptual 256-color fallback for Terminal.app. Zero config
Supersampling	1x/2x/3x factor for higher fidelity at the cost of compute
Cross-platform	macOS and Linux

Quick start

Requires Rust 1.80+ (rustup update to upgrade)

# Install from crates.io (recommended)
cargo install tortuise

# Or build from source
git clone https://github.com/buildoak/tortuise.git
cd tortuise
cargo install --path .

# Built-in demo (no scene file needed)
tortuise --demo

# Load a bundled scene
tortuise --flip-y scenes/bonsai.splat

# Load any .ply or .splat file
tortuise your-scene.splat
tortuise your-scene.ply

# Some scenes need axis flips depending on capture coordinate system
tortuise --flip-y scene.ply
tortuise --flip-z scene.splat

CLI options

tortuise [OPTIONS] [INPUT]

Arguments:
  [INPUT]    Path to a .ply or .splat scene file (use --demo for built-in scene)

Options:
  --demo              Run built-in demo scene
  --flip-y            Flip Y axis (some capture tools use Y-down)
  --flip-z            Flip Z axis
  --supersample <N>   Supersampling factor [default: 1]
  --cpu               Force CPU rendering
  -h, --help          Print help
  -V, --version       Print version

Controls

Free mode

Key	Action
W / A / S / D	Move forward / left / back / right
R / F	Move up / down
Arrow keys	Yaw and pitch (look around)
Space	Switch to Orbit mode
M	Cycle render mode
+ / -	Adjust movement speed
Tab	Toggle HUD
Z	Reset camera
Q / Esc	Quit

Orbit mode

Key	Action
Arrow Up / Down	Adjust elevation
Arrow Left / Right	Nudge orbit angle
Space	Switch to Free mode
+ / -	Adjust orbit speed

Supported terminals

Truecolor (best experience): Ghostty, iTerm2, Kitty, WezTerm, Alacritty

256-color fallback: Apple Terminal.app – works, but reduced color fidelity. The perceptual color mapping does its best.

Auto-detected via COLORTERM, TERM_PROGRAM, and TERM environment variables. No configuration needed.

Tested hardware

Device	CPU	Scene	Reference FPS
Mac Mini M4	Apple M4	luigi.ply (14K)	120+
Mac Mini M4	Apple M4	bonsai.splat (1.1M)	80+
MacBook Air M2	Apple M2	luigi.ply (14K)	✓
MacBook Air M2	Apple M2	bonsai.splat (1.1M)	20–30
Jetson Orin Nano*	ARM Cortex-A78AE	luigi.ply (14K)	~30
Jetson Orin Nano*	ARM Cortex-A78AE	bonsai.splat (1.1M)	10–15

Numbers in parentheses are splat counts. FPS is approximate and depends heavily on terminal window size — a smaller window (⌘-) renders fewer cells and runs faster. *Jetson tested over SSH, which may be a bottleneck.

Where to get scenes

The fastest way to get a real scene into tortuise is to grab one from SuperSplat – thousands of community-uploaded Gaussian splat scenes. The included scripts/supersplat-dl.sh downloads and converts any SuperSplat scene to a standard PLY in one command:

# Download a SuperSplat scene (paste any share URL or scene ID)
./scripts/supersplat-dl.sh "https://superspl.at/s?id=cf6ac78e" bee.ply

# View it
tortuise bee.ply

Requires Node.js 16+ and curl (for npx @playcanvas/splat-transform under the hood).

Other sources:

• tortuise --demo – instant built-in demo scene, no downloads required
• Polycam – photogrammetry captures, some with Gaussian splat export
• nerfstudio – train your own splats from video, exports to .ply
• Any standard 3DGS pipeline output in .ply or .splat format

Both formats are well-supported: PLY files with spherical harmonic coefficients (f_dc_0/1/2) or direct RGB, and the compact 32-byte .splat format used by most web viewers.

How it works

The pipeline is straightforward: load splats, project them into screen space, depth-sort, splat onto a framebuffer, then convert to terminal characters. Each frame:

1. Project – every Gaussian is transformed from world space through the camera view matrix. Frustum culling drops anything behind the near plane or outside the viewport. This step is parallelized with rayon.
2. Sort – projected splats are depth-sorted back-to-front for correct alpha compositing.
3. Rasterize – each splat is splatted onto an RGB framebuffer using its 2D covariance (scale + rotation). Front-to-back compositing with early alpha termination – once a pixel is fully opaque, all remaining splats behind it are skipped. Per-splat saturation probes skip entire Gaussians when they land on already-saturated regions. At 1M+ splats, the back 80% are often invisible behind the front 20%.
4. Encode – the framebuffer is converted to terminal output. In halfblock mode, each cell packs two vertical pixels using the ▄ character with separate foreground/background colors. Other modes use braille patterns, ASCII density ramps, or single characters.

The frame target is 8ms (~120fps). On truecolor terminals, colors are passed as 24-bit RGB. On 256-color terminals, a perceptual distance function maps each pixel to the closest ANSI color – weighted toward green sensitivity, which is where human vision is sharpest.

Roadmap

Things I want to improve next – and contribution opportunities:

• Kitty graphics protocol – pixel-perfect rendering via the terminal image protocol. Roughly 18x the resolution of half-block characters. This is the big one.
• SHARP integration – image-to-splat-to-view pipeline. Single photo to 3D in your terminal.
• Sample scene bundle – curated downloadable scenes so people can skip the “where do I find a .splat file” step.
• GPU acceleration – a Metal compute backend exists behind a feature flag, but needs work at higher resolutions. Parked, not abandoned.
• Performance – radix sort for depth ordering, SIMD-accelerated projection via glam, tighter memory layout.

Built with

• Rust
• crossterm – terminal control and input
• rayon – data parallelism for projection and rasterization
• clap – CLI argument parsing

ratatui + tortoise = tortuise.

License

MIT – Nick Oak, 2026
